    2 Inch Thermal Printer Mechanism With Auto Cutter Auto Paper Loading Support USB

    Ask Lasest Price
    Brand Name : WOOSIM
    Model Number : PORTI-T80/T200
    Certification : CE,FCC,ROHS
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000PCS/WEEK
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    2 Inch Thermal Printer Mechanism With Auto Cutter Auto Paper Loading Support USB

    2 inch kiosk ticket receipt thermal printer with auto cutter


    PORTI-T80/T200


    - Very silent printing thru direct thermal printing method.

    - High resolution(203dpi : 8dots/mm).

    - UART(RS-232C or TTL), USB

    - Low power consumption.

    - Auto cutting.


    ItemSpecification
    PrintingDirect thermal line printing
    Paper loadingAuto paper loading
    Characters per line42cpl(MAX)
    Character sizeEng. : 9x24dots, 12x24dots
    Kor. : 16x24dots [24x24dots]
    Resolution203dpi, 8dots/mm
    Print width2-inch (48mm, 384dots)
    Printing speed60mm/sec(MAX)
    Dimensions (WxDxH)T80 : 190x87.5x103mm [standard model]
    T200 : 310x129x86mm
    WeightT80 : 797g, T200 : 1,102g
    InterfaceUART(RS-232C)
    Paper suppliedThermal roll paper, label roll (60mm wide, 80ø or 200ø),
    Paper thickness : 60±5㎛
    Barcode supported1-dimension : Code128, Code39, I2/5, Code93, UPC-A, UPC-E,
    EAN8, EAN13, CODABAR
    2-dimension : PDF417, QR Code, DATA Matrix, Micro PDF417,
    Truncated PDF417
    DriverMicrosoft Widows XP / VISTA / 7
    Windows CE, Linux, Android, Blackberry
    H/W specMCU : 32bits RISC, FLASH : 4Mbytes, RAM : 8Mbytes
    Receive buffer size1M bytes
    Input Power12~24VDC, Standby 60mA and 3.0A
    OptionSliding mount assembly [T80]
    Operating temperature-10°C~50°C
    Storage temperature-10°C~70°C
    MCBF(Mean Cycle Between failure)Mechanical37,000,000 lines
    HeadApproximately 50 Km
